High Capacity Horizontal Dryers/Coolers

Wenger Dryers are Customized to Meet Process and Capacity Requirements

Airflow II - The industry standard for post-extrusion drying/cooling



  • Wide variety of configurations, materials, and sizes
  • Horizontal and vertical dryers
  • 1-3 passes available
  • Heat source can be gas, steam, or electric
  • Adjustable air flows for optimal processing control and efficiency
  • Sanitary configurations available
  • Heated airflow from both sides of dryer
  • Heavy duty construction
  • Units are assembled and tested in our factory before shipped to ensure quality and performance
  • Technical assistance available 24 hours a day
  • Process Air Flexibility

    Dryers can be configured for optimum airflow. High process airflow velocity through the product bed increases drying energy efficiency while maximizing final product moisture uniformity.



    Temperature profiling is optionally available in the TrueTemp configuration. This means each conveyor has separate temperature zones so the temperature can be matched to the product drying curve.

  • Process Control Options

    Unique dryer control systems are designed for greater process efficiency. We offer full Automated Process Management systems linking the dryer to up or downstream components.

  • Multiple Product Spreader Options

    Uniform drying is dependent on uniform bed loading. We offer several options for in-feed product spreaders:

    • Sloped oscillating spout spreader — suitable for most applications
    • Oscillating belt
    • Finger
    • Rake
    • Vibratory
    • Self adjusting leveling auger
  • Heat Source Options

    Direct Heat

    • Provided by natural gas, propane or butane
    • Delivered to your work site with complete pre-plumbed, pre-wired gas train
    • Equipped with safety interlocks meeting FM requirements



    Indirect Heat

    • Provided by heavy duty stainless steel coils protected by externally replaceable wire mesh screens
    • Includes manifold, valves, traps and necessary plumbing components
  • Product Conveyor Options

    Hinged or overlapping design with heavy duty tray is available in galvanized carbon steel or type 304 stainless steel construction. Tray perforations may be round holes or slots depending on the application. Woven screen continuous conveyors carried on heavy duty supports are optionally available for low or high temperature applications for small product sizes.

Talk to a Product Specialist

to discuss the feasibility, design and implementation for your project
